NorthStar 117ltr Tow-Behind Trailer Boom Broadcast & Spot Sprayer


Southside Stockfeeds Kilmore proudly stocks the NorthStar 117ltr Tow-Behind Trailer Boom Broadcast & Spot Sprayer.

The versatile, high-end NorthStar Tow-Behind Trailer Boom Broadcast and Spot Sprayer give you the ability to do both precision and wide-coverage spraying. Equipped with a commercial-grade NorthStar NSQ Series pump, it provides easier priming, exceptional durability and superior resistance to harsh environments and corrosive chemicals. The completely redesigned, the over-sized tank is secured to a heavy-duty 100% steel cart that handles the roughest terrain. A retractable tow-bar, foldable boom arms and removable axle and wheels allow for ultra-compact storage. Litres marks are moulded into the tank for easy fluid level monitoring. Tow behind your ATV or lawn/garden tractor.

  • 12V, 70PSI max open flow NorthStar NSQ Series on-demand pump provides faster priming and longer life.
  • 100% continuous duty rating
  • Honeywell MICRO SWITCH for enhanced durability and efficiency
  • Santoprene™ diaphragm and Viton® valves for superior reliability and chemical resistance
  • Large-capacity proprietary tank design features extra-thick walls that are UV-resistant and compatible with virtually all pesticides
  • Boom arms fold up for easy storage
  • 1m boom width with 3m overall broadcast width
  • Spring-loaded, breakaway boom arms fold away for compact storage
  • Left and right boom nozzle control valves
  • Control system pressure and fluid agitation with regulator and pressure gauge
  • Approved for use with Roundup® agricultural herbicide
  • Spot spray gun nozzle adjusts from cone to stream; shoots 5.7m vertically and 9.1m. horizontally
  • 5m clear PVC hose makes monitoring chemical flow simple
  • Rugged powder-coated steel cart with large 30cm pneumatic wheels
  • 19cm diameter tank lid for easy fills
  • Easy empty tank with bottom drain
  • Includes pressure gauge and remote switch with battery clips
  • Attaches to ATV or garden tractor


TB49-49L TB79-79L TB117-117L TB155-155L TB230-230L TB380-380L
Tank Size 49 Litre 79 Litre 117 Litre 155 Litre 230 Litre 380 Litre
Pump Pressure 40 PSI 70 PSI 70 PSI 60 PSI 60 PSI 60 PSI
Pump Flow 3.8 LPM 8.3 LPM 8.3 LPM 15.1 LPM 20.8 LPM 26.5 LPM
Pump Supply 12V DC
Regulator/ Agitator Yes
Pressure Guage 51mm 51mm 51mm 51mm 51mm 51mm
Spray Pattern Stream, Cone, Broadcast
Broadcast Width 1.07m 2.13m 2.13m 2.53m 3.57m 4.57m
Boom Width 0m 1.07m 1.07m 1.98m 3.05m 4.11m
Boom Material Steel
Boom Control None Left / Right Left / Right Left / Center / Right Left / Center / Right Left / Center / Right
Boom Features Single Bracket Folds for Storage Spring Breakaway Ball Valve Control
Nozzle Quantity 1 2 2 5 7 9
Nozzle Type Deflectip Deflectip Deflectip Fan Fan Fan
Spray Gun Spot Spot Spot Deluxe Spot Deluxe Spot Deluxe Spot
Spray Height 3.66m 5.79m 5.79m 6.71m 9.14m 10.67m
Gun Hose 9.5mm x 3.35m
Hose Wrap Steel Brackets
Suction Strainer 9.5mm Mushroom 13mm Mushroom 13mm Mushroom 19mm Mushroom 19mm Mushroom Inline
Tank Cap 178mm Tethered
Wheels 254mm 305mm 305mm 406mm 406mm 457mm
Hub Plastic Bushing
Cart Material Steel
Axle 16mm Loose 25.5mm Fixed
Retractable Tow Bar No Yes
Wire Harness 2.44m
CE Yes Yes Yes Yes (Pending) Yes (Pending) Yes (Pending)
Warranty 2 Years
